HC1200*2A 380V Hammer Mill Crusher Equipment For Mineral Processing

HC1200*2A Hammer Crusher for Minerals Materials Processing Equipment, the dual-rotor hammer crusher is mainly used in materials processing in clay brick making plant or other minerals processing industries.

Specifications of HC1200*2A Hammer Crusher for Minerals Materials Processing Equipment

HC1200*2A Hammer Crusher for Minerals Materials Processing Equipment running in Brick making factory.

Questions about HC1200*2A Hammer Crusher for Minerals Materials Processing Equipment

1. The Power is 320kw, this power is for 2 motors or only one motor?

           A: 320kw=160kw+160kw, there are 2 motors instead of one 320kw;

2. The two electric motors have the same power, or one big, and the second one samll?

        A: the two motors have the same power.

3. The brand of of motors?

          A: Brand is Anhui Liuan, China brand with good quality.

4. The hammer head are the same models in the machine?

          A:the hammer head are same.

5. The quantity of hammer in the machine? And weight of each hammer heads ?

          A: totally 36 hammers=18 hammers upper +18 hammers in lower of the machine.

              Weight of each hammers is 22kg.

6. The service life of head hammer?

           A: if working time is 8 hours per day, service life of the hammer is 3-8 months, according to the different materials.

7. The machine is delivered with electrical cabinet or not?

         A: the machine is delivered without electrical cabinet, the machine can running with power connect directly.

8. What is the imput granularity required for the machine to work perfectly? And what is the final granularity the machine can give?

         A:input diameter of raw materials is less 250mm, 90% output is less than 3mm, 10% output is 3-5mm.

9. When the raw materials is wet, the machine can crush it wihout sticking or not?

         A: Water content not more than 8.5%, raw materiasl will not stick on the machine.

10. The brand of bearings of machine?

         A: bearings brand is Wafangdian, good quality in China.
