Automatic Tunnel Kiln Car Cleaning System for Brick Factories

Automatic Tunnel Kiln Car Cleaning System for Brick Factories

Working Process of Cleaning equipment for brick tunnel kiln car China Supplier Kiln Cart Sweeper:

① After the kiln car stops at the cleaning position, the lifting dust suction unit extends to the working height. Meanwhile, the suction system and rolling brush start operating, removing dust from the kiln car surface and gaps.

② When the moving assembly reaches the end of the kiln car, cleaning is completed. The dust suction unit lifts up, then moves together with the roller brush to the next kiln car. The suction unit extends again to start the next cycle.

③ Collected dust is stored in the ash hopper and discharged regularly into a collection box via an electric discharger.

Automated Kiln Car Sweeping & Cleaning Equipment System for Automatic Brick Plants



Why need the automatic vacuum cleaner for kiln car cleaning?

During the firing process of clay bricks, the brick factory will generate dust,Because the internal combustion of burning bricks is not sufficient, coal and combustion accelerants are added to the raw materials to help on fire, when burning, dust will float into the air. Dust particles as the kiln car leaves the kiln with fired bricks will leave together.
After the fired bricks are unloaded from the kiln car, the large particles on the surface of the kiln car can be cleaned manually, but there is dust in the car
The kiln car cannot be cleaned thoroughly and will damage the kiln car in the future.
BBT vacuum cleaners are designed for thorough cleaning of kiln cars, which are both environmentally friendly and cost-effective.



Automatic Brick Kiln Car Cleaning Equipment System



Automatic brik kiln car cleaning system of technical parameters for your reference :

Item	Parameter
Equipment Name	Automatic Kiln Car Cleaning System / Kiln Cart Sweeper
Applicable Scene	Brick tunnel kiln production line
Cleaning Method	Rolling brush + vacuum dust collection
Cleaning Object	Kiln car surface, gaps and residual dust
Lifting Stroke of Suction Unit	Customizable according to kiln car size
Moving Mode	Electric walking / rail moving
Dust Collection Method	Centralized dust hopper with electric discharger
Control Mode	Automatic / manual integrated control
Power Supply	380V 50Hz (customizable)
Working Environment	High temperature resistant for kiln car area
Features	Fully automatic, continuous operation, high efficiency, low dust emission
