Customized Vacuum Mud Pug Mill For Pottery Clay Brick Floor Tile Extruder Machine

Customized Vacuum Mud Pug Mill For Pottery Clay Brick Floor Tile Extruder Machine
Basic Properties
Place of Origin: China
Brand Name: BBT
Certification: ISO9001:2008
Model Number: 220T
Trading Properties
Minimum Order Quantity: 1 Set
Price: 4000- 8000usd per set
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 20 Sets/30 days
Tags:

Vacuum Extruder Clay Brick

Vacuum Brick Machine Production Line

Mixing Shaft Vacuum Extruder Clay Brick
Product Summary
Customized Vacuum Mud Pug Mill For Pottery Clay Extruder Machine For Ceramic Mini Brick Floor Tile Introduction of Customized Vacuum Mud Pug Mill For Pottery Clay Extruder Machine For Ceramic Mini Brick Floor Tile 1. vacuum mud mixer is the main professional machinery in the ceramic industry. 2. It ...
Product Custom Attributes
Highlight

Customized Vacuum Mud Pug Mill

,

Pottery Clay Extruder Machine

,

Mini Brick Floor Tile Pug Mill

Condition:
New
Materials:
Cast Iron Or Sst.
Key Selling Points:
Samll Size, Low Price
Brand Name:
BBT
Usage:
Laboratory Use Or Clay Dough Products
Warranty:
12 Months
After-sales Service:
Video Technical Support, Online Support, Spare Parts
Applicable Industries::
Clay Mud, Ceramics, Bubble Mud
Product Description
Detailed Specifications & Features

Customized Vacuum Mud Pug Mill For Pottery Clay Extruder Machine For Ceramic Mini Brick Floor Tile



Customized Vacuum Mud Pug Mill For Pottery Clay Brick Floor Tile Extruder Machine 0



Introduction of Customized Vacuum Mud Pug Mill For Pottery Clay Extruder Machine For Ceramic Mini Brick Floor Tile



1. vacuum mud mixer is the main professional machinery in the ceramic industry.

2. It is mainly used for the preparation of mud for bricks and tiles, daily-use porcelain and industrial porcelain.

3. Various molds are added to the front of the mud outlet to extrude various ceramics. And tile-shaped and other ceramic components mud. If used in the automatic production line of daily-use ceramic molding, it can become an automatic quantitative feeder.



Customized Vacuum Mud Pug Mill For Pottery Clay Brick Floor Tile Extruder Machine 1





Technical parameters of Customized Logo Vacuum Mud Pug Mill Clay Extruder Machine For Making Ceramic Mini Brick Floor Tile



Model
TC100
TC150
TC200
TC250
Power
3kw 380v
3kw 380v
4kw 380v
11~15kw 380v
Motor Speed
1440R
1440R
1440R
1440R
Spiral diameter
100mm
150mm
200mm
250mm
Outlet head diameter
20~70mm
25~95mm
40~130mm
140~180mm
Capacity
0.4~0.5t/h
0.6~1t/h
1~2t/h
3~5t/h
Dimension
100*35*55cm
100*55*60cm
115*70*65cm
215*80*88cm
Weight
120kg
220kg
270kg
800kg



Customized Vacuum Mud Pug Mill For Pottery Clay Brick Floor Tile Extruder Machine 2



Customized Vacuum Mud Pug Mill For Pottery Clay Brick Floor Tile Extruder Machine 3
