Full Automatic Plate Box Feeder Machine with Chain Travel Track and Frequency Conversion Speed Regulation
Full Automatic Plate Box Feeder Machine with Chain Travel Track and Frequency Conversion Speed Regulation
Basic Properties
Place of Origin:
China
Brand Name:
BBT
Certification:
ISO9001
Model Number:
TCNL1260
Trading Properties
Minimum Order Quantity:
1 Set
Payment Terms:
L/C,T/T,Western Union
Supply Ability:
15 sets per month
Product Summary
Full Automatic Clay Brick Making Project Plate Box Feeder Machine with 7.5kw Power The plate feeder Clay Brick Box Feeder Machine for full automatic clay brick making project. Automatic Plate Box Feeder Features Automatic plate box feeder for materials storage and feeding for clay brick production ...
Product Custom Attributes
Highlight
Full Automatic Clay Brick Making Machine
,7.5kw Power Clay Brick Making Machine
Item:
The Plate Feeder Clay Brick Box Feeder Machine
Voltage:
380V
Processing:
Brick Production Line
Capacity ( M3/h):
50-80
Chain Travel Track Center Distance (mm):
1375
Power (kw):
7.5
Weight (kg):
10800
Product Description
Detailed Specifications & Features
Full Automatic Clay Brick Making Project Plate Box Feeder Machine with 7.5kw Power
The plate feeder Clay Brick Box Feeder Machine for full automatic clay brick making project.
Automatic Plate Box Feeder Features
Automatic plate box feeder for materials storage and feeding for clay brick production line.
- The driving motor of the transmission system is the frequency conversion of speed regulation
- The feeding system is driven separately from the mud stick
- The completed machine has a reasonable structure, reliable performance, convenient maintenance, low running resistance and low energy consumption
- Equipped with manual adjustment gate. The feeding amount of the raw material can be controlled by adjusting the height of the gate and the speed of the motor
- For the mud stick can choose different structures and types, in addition to the material shifting functions, it can also break up larger block of soft mud
Clay Brick Box Feeder Technical Parameters
| Item | Unit | TCNL1045 |
|---|---|---|
| Production capacity | m3/h | 15-50 |
| Center distance (Driving and tighten sprocket) | mm | 4500 |
| Center distance of chain track | mm | 1175 |
| Required power | Kw | 4 |
| Approximate weight | Kg | 6200 |
