Double Tooth Roller Crusher Machine Full Automatic For Tunnel Kiln Plant

The Roller Crusher Machine Tooth Roll Crushing Machinery

Full automatic clay brick making production line raw materials crushing equipment double toothed roller crusher machine

The roller crusher machine tooth roll crushing machinery for tunnel kiln plant

TRA400X1000 double toothed roller crusher is a new product developed by our company on the basis of absorbing the advanced experience of similar products abroad, and it occupies a leading position among similar products in China.

The machine is reasonable in structure, stable in operation, low in failure rate, and easy to use and maintain.

It is suitable for the crushing of brittle and soft materials such as sintered bricks, coal, cement, silicate, glass, ceramics, etc.

It is mainly used for medium and fine crushing operations.

This machine is used for rough crushing of 50-300mm bulk materials, and crushing to below 30mm. According to the characteristics of raw materials, the output varies from 20-100 cubic meters per hour.

Working principle and structural characteristics:

This series of double toothed roller crusher is mainly composed of motor, reducer, hydraulic coupling, frame part, fender part, gear box, fast and slow rollers, pressing roller components and other parts. The working gap of the double rollers is 16mm, which can meet the requirements of medium crushing of materials. The trowel can ensure that the materials sticking to the roller grooves are removed, and the maintenance and replacement are also convenient; the motor and the reducer are connected by a torque-limiting hydraulic coupling. , which can effectively prevent overload; the roller tooth head is welded with carbide, which greatly improves its long service life; the unique design of the main shaft structure of the fast and slow rollers fundamentally improves the reliability and service life of the whole machine; the main body adopts All-steel structure improves the strength and service life of the equipment; the equipment has the characteristics of large crushing ratio, low noise, low vibration, small dust pollution, small footprint, simple structure and convenient maintenance; the machine is equipped with a pressing shaft to facilitate Large pieces of material are easier to enter into the crushing roller to improve the efficiency of the crusher.

Roller crusher machine double tooth rolling crusher of technical parameters:

Double toothed roller crusher machinery for clay brick tunnel kiln project
