Pneumatic Column Hollow Block Cutting Machine Brick Cutter Machine
Pneumatic Block Cutting Machine
,Hollow Block Cutting Machine
Clay brick plant pneumatic column hollow block cutting machine brick cutter machineClay brick plant pneumatic column hollow block cutting machine brick cutter machine
Clay brick plant pneumatic column hollow block cutting machine brick cutter machine
This model is the most used.
The pneumatic column cutting machine is combined with the super blue brick cutting machine to realize unmanned operation, saving labor, when encountering a failure of an automatic system.
The brick cutting machine is suitable for a wide range of applications, such as soft extrusion, semi-hard extrusion and hard extrusion of clay, coal gangue, fly ash, shale mud.
Technical parameters of clay brick cutting machine:pneumatic column hollow Block Cutting Machine Auto Hydraulic Pressure
| No. | Item | Power (kw) | Speed and specifications | Dimension (mm) |
| 1 | Automatic column cutter | 1.1+0.75 | cutting length:1800mm-2000mm | Custom building |
| 2 | Acceleration belt bench | 1.5 | 0-1m/s | Custom building |
| 3 | 90°lifting reversing bench | 2.2+1.5+1.1 | 1m/s | Custom building |
| 4 | Automatic green brick cutter | 5.5+1.1 |
cutting length 190mm, 8 bricks/time Cutting cycle 6-8 times/min Maximum cutting height 240 mm Maximum cutting width 520 mm |
|
| 5 | Electrical control boards for above machines | / | / | Custom building |
Clay brick plant pneumatic column hollow block cutting machine brick cutter machine
