Big Solid Block Clay Brick Cutting Machine Hydraulic Pressure Customized
Big Clay Brick Cutting Machine
,Customized Clay Brick Cutting Machine
,Hydraulic Pressure Solid Block Cutting Machine
Big Type Clay Brick Cutting Machine Price
Auto brick cutting machine clay brick cutter red brick making machine brick wall cutting machine
Small type full automatic clay brick cutter machine Big type clay brick cutting machine price
This model is the mostly used. A combination of pneumatic column cutting machine and super green brick cutter,that realizes the operation without workers so that it can save labours and when meets one automatic system failur.
This brick cutter is suitable to a wide range, such as clay, coal gangue, fly ash, shale mud soft extrusion,semi-stiff extrusion and stiff extrusion.
Fully automatic clay brick making line clay brick cutter machinery
Technical parameters of clay brick cutting machine
| No. | Item | Power (kw) | Speed and specifications | Dimension (mm) |
| 1 | Automatic column cutter | 1.1+0.75 | cutting length:1800mm-2000mm | Custom building |
| 2 | Acceleration belt bench | 1.5 | 0-1m/s | Custom building |
| 3 | 90°lifting reversing bench | 2.2+1.5+1.1 | 1m/s | Custom building |
| 4 | Automatic green brick cutter | 5.5+1.1 |
cutting length 190mm, 8 bricks/time Cutting cycle 6-8 times/min Maximum cutting height 240 mm Maximum cutting width 520 mm |
|
| 5 | Electrical control boards for above machines | / | / | Custom building |
Clay brick cutting machine shipment
Clay brick cutting machinery in auto brick making line
