Product Details:
Place of Origin: China
Brand Name: BBT
Certification: ISO9001:2008

Red Clay Refractory Brick Material Hydraulic Pressure Customized

Description
Condition: New Method: Hydraulic Pressure, Manual Pressing
Processing: Brick Production Line Aplications: Bricks And Ceramics Plant
Function: Fired Bricks Raw Material: Synthetic Material Clay
Place Of Origin: Shaanxi, China Size: Customized
Highlight:

Customized Refractory Brick Material

,

Hydraulic Pressure Refractory Brick Material

,

Red Refractory Clay Bricks

Refractory Brick Material In Clay Brick Plant Red Clay Brick Production Line Fired Bricks



Products description of Refractory Bricks in Clay Brick Plant Red Clay Brick Production Line Fired Bricks



Low thermal conductivity anti-stripping brick is characterized by: synthesizing low thermal conductivity and alkali-resistant raw materials, using alumina fine powder, andalusite and bound clay as raw materials, mixing to make mixed powder, and then adding the mixed powder into a binder, pressing After forming, drying and firing, the bricks with low thermal conductivity and spalling resistance are obtained.



Application of refractory bricks in red clay brick production line of clay brick factory Fired bricks: tunnel kiln; cement kiln: safe area, rotary kiln preheating/calcining area.



Features of refractory bricks for clay brick factory Red clay brick production line Fired bricks: Excellent resistance to alkali erosion Excellent thermal shock resistance Low thermal conductivity Reduced kiln shell load, lining mechanical stress



Parameters of Refractory Bricks in Clay Brick Plant Red Clay Brick Production Line Fired Bricks : Outstanding resistance to alkali attack Excellent thermal-shock resistance Low thermal conductivity Decreasing the kiln shell load, the mechanical stress on the lining



CHEMICAL COMPOSITION
SPEC TYPICAL
Al2O3


% ≤35 32-34
SiO2


%


62-64
Fe2O3


% ≤1.8 1.6
PHYSICAL PROPERTIES




SPEC TYPICAL
Thermal Shock Resistance TSR - in water at 1100 °C cycle ≥15 16
Refractoriness Under Load RUL (0.2MPa) °C ≥1310 1330
Thermal Expansion TE- 1000 °C %


0.6
Cold Crushing Strength CCS MPa ≥45 57
Thermal Conductivity TC - 700士25 °C W/m.K ≤1.5 1.5
Alkali Resistance 1100 °C*5h


First grade



Applications of Refractory Bricks in Clay Brick Plant Red Clay Brick Production Line Fired Bricks in Brick Making Plant.



Red Clay Refractory Brick Material Hydraulic Pressure Customized 0



Red Clay Refractory Brick Material Hydraulic Pressure Customized 1
